Audit logs track the changes and activities that occur in the virtual nodes due to user actions. You can filter the logs to view specific information.

Access Audit Logs
Navigate to Dashboard > SYSTEM > Audit Logs. The All Audit Logs page appears.

Parameters
The Audit Logs have the following parameters:

Parameters	Description
Time	Provides the timestamp on the log entries.
User	Provides the logged user information.
Operation Type	Provides specific entries that the system logs. For example, ■   Log in and Log out based on users. ■   Create/Delete/Edit tasks, GS operations, maps, virtual ports, and so on.
Source	Provides details about the usage either in GigaVUE‑FM or on the node when the event occurred.
Status	Success or Failure of the event.
Description	For failed status provides a brief update on the reason..

Note:  Verify if the GigaVUE-FM time is set correctly to ensure accuracy of the captured trending data.

Filtering the audit logs

You can filter to view specific type of logs based on the following criteria:

• When: Displays logs that occurred within a specified time range.
• Who: Displays logs related to a particular user or users.
• What: Displays logs for one or more operations, such as Create, Read, and Update.
• Where: Displays logs for GigaVUE‑FM or devices.
• Result: Displays logs for success or failure.

To filter the audit logs,

1. Select Filter.

   A quick view for Audit Log Filters displays.

2. Specify one or all of the following:

   • Start Date and End Date to display logs within a specific time range.

   • Who limits the scope of what displays on the Audit Logs page to a specific user or users.

   • What narrows the logs to the types of operation that the log is related to. You can select multiple operations. Select All Operations to apply all operation types as part of the filter criteria.

   • Where narrows the logs to particular of system that the log is related to. Select All Systems apply both GigaVUE‑FM and device to the filter criteria. Result narrows the logs related to failures or successes. Select All Results to apply both success and failure to the filter criteria.

3. Select OK to apply the selected filters to the Audit Logs page.
